## Source — styles.css
````css
:root {
--size-unit: 16;
--size-container-ideal: 1440;
--size-container-min: 992px;
--size-container-max: 1920px;
--size-container: clamp(
var(--size-container-min),
100vw,
var(--size-container-max)
);
--size-font: calc(
var(--size-container) / (var(--size-container-ideal) / var(--size-unit))
);
--color-bg: #f3eee6;
--color-card: #fffcf8;
--color-ink: #1f1b16;
--color-muted: #8a7e72;
--color-dot: #c9bfb3;
--color-line: rgba(31, 27, 22, 0.08);
--color-shadow: 0 1.25em 2.5em rgba(31, 27, 22, 0.08);
--font-ui: "Outfit", system-ui, sans-serif;
--font-display: "Cormorant Garamond", "Times New Roman", serif;
}
@media screen and (max-width: 991px) {
:root {
--size-container-ideal: 834;
--size-container-min: 768px;
--size-container-max: 991px;
}
}
@media screen and (max-width: 767px) {
:root {
--size-container-ideal: 550;
--size-container-min: 480px;
--size-container-max: 767px;
}
}
@media screen and (max-width: 479px) {
:root {
--size-container-ideal: 390;
--size-container-min: 320px;
--size-container-max: 479px;
}
}
*,
*::before,
*::after {
box-sizing: border-box;
}
html {
scrollbar-width: none;
}
html,
body {
margin: 0;
padding: 0;
-webkit-font-smoothing: antialiased;
-moz-osx-font-smoothing: grayscale;
}
body::-webkit-scrollbar,
body ::-webkit-scrollbar {
display: none;
}
body {
color: var(--color-ink);
background-color: var(--color-bg);
font-family: var(--font-ui);
font-size: var(--size-font);
font-weight: 400;
line-height: 1.25;
-ms-overflow-style: none;
}
button {
font: inherit;
color: inherit;
background: none;
border: 0;
margin: 0;
padding: 0;
appearance: none;
-webkit-appearance: none;
}
img {
max-width: 100%;
display: block;
-webkit-user-drag: none;
}
.main {
overflow: clip;
}
.demo-section {
position: relative;
display: flex;
min-height: 100dvh;
background-color: var(--color-bg);
}
[data-spatial-slider-init] {
--slider-gap: 2.5em;
--slider-curve: 30deg;
--slider-perspective: 120em;
--slider-direction: 1;
}
.demo-section + .demo-section [data-spatial-slider-init] {
--slider-curve: 20deg;
--slider-direction: -1;
}
.spatial-gsap-slider {
position: relative;
display: flex;
flex-flow: column;
justify-content: center;
align-items: center;
width: 100%;
padding-top: 10em;
padding-bottom: 5em;
row-gap: 5em;
}
[data-spatial-slider-drag-status="grab"] {
cursor: grab;
}
[data-spatial-slider-drag-status="grabbing"] {
cursor: grabbing;
}
.spatial-gsap-slider__collection {
position: relative;
max-width: 100%;
}
.spatial-gsap-slider__list {
position: relative;
display: flex;
justify-content: center;
align-items: center;
max-width: 100%;
column-gap: var(--slider-gap);
perspective: var(--slider-perspective);
transform-style: preserve-3d;
backface-visibility: hidden;
user-select: none;
-webkit-user-select: none;
touch-action: pan-y;
will-change: transform;
}
.spatial-gsap-slider__item {
position: absolute;
flex: none;
transform-style: preserve-3d;
backface-visibility: hidden;
will-change: transform;
}
[data-spatial-slider-list] > :first-child {
position: relative;
}
.demo-card {
display: flex;
flex-flow: column;
align-items: flex-start;
width: 18em;
padding-top: 0.625em;
padding-left: 0.625em;
padding-right: 0.625em;
color: var(--color-ink);
text-align: center;
background-color: var(--color-card);
border: 1px solid var(--color-line);
border-radius: 1.375em;
box-shadow: var(--color-shadow);
}
.demo-card__media {
position: relative;
width: 100%;
aspect-ratio: 1;
border-radius: 0.75em;
overflow: hidden;
}
.cover-image {
position: absolute;
top: 0;
left: 0;
width: 100%;
height: 100%;
object-fit: cover;
border-radius: inherit;
pointer-events: none;
}
.demo-card__info {
display: flex;
justify-content: center;
align-items: center;
width: 100%;
height: 3.5em;
padding-left: 0.75em;
padding-right: 0.75em;
}
.demo-card__h {
margin: 0;
font-family: var(--font-display);
font-size: 1.45em;
font-weight: 600;
line-height: 1;
letter-spacing: 0.12em;
text-transform: uppercase;
}
.spatial-gsap-slider__controls {
position: relative;
display: flex;
justify-content: center;
align-items: center;
column-gap: 1em;
padding-left: 3em;
padding-right: 3em;
}
.spatial-gsap-slider__control-btn {
position: relative;
z-index: 1;
display: grid;
place-items: center;
width: 3em;
height: 3em;
padding: 0;
color: var(--color-ink);
background-color: var(--color-card);
border: 1px solid var(--color-line);
border-radius: 50%;
box-shadow: 0 0.35em 1em rgba(31, 27, 22, 0.06);
cursor: pointer;
}
.spatial-gsap-slider__control-btn svg {
width: 1.15em;
height: 1.15em;
display: block;
}
.spatial-gsap-slider__control-btn:focus-visible,
.spatial-gsap-slider__control-dot:focus-visible {
outline: 2px solid var(--color-ink);
outline-offset: 3px;
}
.spatial-gsap-slider__dots {
display: flex;
justify-content: center;
align-items: center;
gap: 0.4em;
}
.spatial-gsap-slider__control-dot {
position: relative;
z-index: 1;
flex: none;
width: 0.5em;
height: 0.5em;
padding: 0;
color: var(--color-dot);
background-color: currentColor;
border: 0;
border-radius: 50em;
overflow: hidden;
cursor: pointer;
transition:
width 0.55s cubic-bezier(0.25, 0.1, 0, 1),
color 0.45s cubic-bezier(0.25, 0.1, 0, 1),
background-color 0.45s cubic-bezier(0.25, 0.1, 0, 1);
}
.spatial-gsap-slider__control-dot[data-spatial-slider-control-status="active"] {
width: 1.75em;
color: var(--color-ink);
}
.note {
position: absolute;
bottom: 2em;
left: 0;
width: 100%;
margin: 0;
color: var(--color-muted);
font-weight: 400;
letter-spacing: 0.04em;
text-align: center;
}
@media screen and (max-width: 767px) {
[data-spatial-slider-init] {
--slider-gap: 1em;
--slider-curve: 45deg;
}
.demo-card {
width: 15em;
}
.spatial-gsap-slider {
padding-top: 6em;
padding-bottom: 4em;
row-gap: 3em;
}
}
````
## Source — script.js
````javascript
gsap.registerPlugin(Draggable, InertiaPlugin, CustomEase);
CustomEase.create("spatial", "0.25, 0.1, 0, 1");
function initSpatialCardsSlider() {
const slideDuration = 1;
const clickEase = "spatial";
document.querySelectorAll("[data-spatial-slider-init]").forEach((container) => {
if (container._spatialSliderDraggable) container._spatialSliderDraggable.kill();
if (container._spatialSliderImageObserver) {
container._spatialSliderImageObserver.disconnect();
}
if (container._spatialSliderProxy) {
gsap.killTweensOf(container._spatialSliderProxy);
container._spatialSliderProxy.remove();
}
const collection = container.querySelector("[data-spatial-slider-collection]");
const track = container.querySelector("[data-spatial-slider-list]");
if (!collection || !track) return;
gsap.set(track, { clearProps: "transform" });
container.querySelectorAll("[data-spatial-slider-item]").forEach((item) => {
gsap.set(item, { clearProps: "transform" });
});
container.querySelectorAll("[data-spatial-slider-clone]").forEach((el) => el.remove());
const originalItems = Array.from(
track.querySelectorAll(":scope > [data-spatial-slider-item]:not([data-spatial-slider-clone])")
);
if (!originalItems.length) return;
container.setAttribute("role", "region");
container.setAttribute("aria-roledescription", "carousel");
container.setAttribute(
"aria-label",
container.getAttribute("aria-label") || "Spatial Cards Slider"
);
track.setAttribute("role", "group");
track.setAttribute("aria-label", "Slides");
const dotsWrap = container.querySelector("[data-spatial-slider-generate-dots]");
if (dotsWrap) {
const dots = Array.from(dotsWrap.querySelectorAll("[data-spatial-slider-control]"));
if (dots.length) {
const template = dots[0];
dots.slice(1).forEach((dot) => dot.remove());
for (let i = 1; i <= originalItems.length; i++) {
const dot = i === 1 ? template : template.cloneNode(true);
dot.setAttribute("data-spatial-slider-control", String(i));
dot.setAttribute("data-spatial-slider-control-status", "not-active");
if (i > 1) dotsWrap.appendChild(dot);
}
}
}
const controls = Array.from(container.querySelectorAll("[data-spatial-slider-control]"));
const totalEl = container.querySelector("[data-spatial-slider-total-slide]");
const indicators = Array.from(container.querySelectorAll("[data-spatial-slider-active-slide]"));
const mod = (value, total) => ((value % total) + total) % total;
const formatNumber = (value) => (value < 10 ? "0" + value : String(value));
if (totalEl) totalEl.textContent = formatNumber(originalItems.length);
originalItems.forEach((item, index) => {
item.removeAttribute("data-spatial-slider-item-status");
item.removeAttribute("aria-hidden");
item.setAttribute("role", "group");
item.setAttribute("aria-label", `Slide ${index + 1} of ${originalItems.length}`);
});
controls.forEach((btn) => {
const value = btn.getAttribute("data-spatial-slider-control");
if (value === "prev") btn.setAttribute("aria-label", "Previous slide");
if (value === "next") btn.setAttribute("aria-label", "Next slide");
if (/^\d+$/.test(value)) {
btn.setAttribute("aria-label", `Go to slide ${value}`);
btn.setAttribute("aria-current", "false");
}
});
const containerStyles = getComputedStyle(container);
const trackStyles = getComputedStyle(track);
const curve = Math.abs(parseFloat(containerStyles.getPropertyValue("--slider-curve"))) || 12;
const directionValue = parseFloat(containerStyles.getPropertyValue("--slider-direction"));
const direction = directionValue < 0 ? -1 : 1;
const gap = parseFloat(trackStyles.columnGap) || 0;
const curveRadians = (curve * Math.PI) / 180;
const firstRect = originalItems[0].getBoundingClientRect();
const itemWidth = firstRect.width;
const itemHeight = firstRect.height;
const perspectiveValue = parseFloat(getComputedStyle(track).perspective);
const perspective = Number.isFinite(perspectiveValue) ? perspectiveValue : 1200;
const getProjectedEdgeX = (radius, angle, side) => {
const radians = (angle * Math.PI) / 180;
const rotation = -direction * radians;
const localX = (side * itemWidth) / 2;
const centerX = Math.sin(radians) * radius;
const centerZ = direction * radius * (1 - Math.cos(radians));
const x = centerX + localX * Math.cos(rotation);
const z = centerZ - localX * Math.sin(rotation);
return (x * perspective) / (perspective - z);
};
let spatialRadius = itemWidth / Math.sin(curveRadians);
for (let i = 0; i < 8; i++) {
const nextLeft = getProjectedEdgeX(spatialRadius, curve, -1);
const currentRight = itemWidth / 2;
const currentGap = nextLeft - currentRight;
const correction = gap - currentGap;
spatialRadius += correction / Math.sin(curveRadians);
}
const stepDistance = Math.sin(curveRadians) * spatialRadius;
const tangentRatio = (-direction * spatialRadius) / (perspective - direction * spatialRadius);
const edgeAngle = (Math.acos(gsap.utils.clamp(-1, 1, tangentRatio)) * 180) / Math.PI;
const maxSideItems = Math.ceil(edgeAngle / curve);
const maxLoopItems = maxSideItems * 2;
const getSpatialPosition = (offset) => {
const angle = gsap.utils.clamp(-edgeAngle, edgeAngle, offset * curve);
const radians = (angle * Math.PI) / 180;
return {
x: Math.sin(radians) * spatialRadius,
z: direction * spatialRadius * (1 - Math.cos(radians)),
rotationY: -direction * angle,
};
};
const containerRect = container.getBoundingClientRect();
const trackRect = track.getBoundingClientRect();
const originX = trackRect.left + trackRect.width / 2;
const leftLimit = containerRect.left - originX;
const rightLimit = containerRect.right - originX;
const isOffsetInside = (offset) => {
if (Math.abs(offset * curve) >= edgeAngle) return false;
const position = getSpatialPosition(offset);
const scale = perspective / (perspective - position.z);
const radians = (Math.abs(position.rotationY) * Math.PI) / 180;
const halfWidth = (Math.abs(Math.cos(radians)) * itemWidth * scale) / 2;
const x = position.x * scale;
return x + halfWidth >= leftLimit && x - halfWidth <= rightLimit;
};
const getVisibleCount = () => {
let left = 0;
let right = 0;
for (let i = 1; i < maxSideItems && isOffsetInside(i); i++) right = i;
for (let i = 1; i < maxSideItems && isOffsetInside(-i); i++) left = i;
return Math.min(maxLoopItems, 1 + left + right + 2);
};
const minItemsNeeded = getVisibleCount();
const neededItems =
originalItems.length >= minItemsNeeded
? originalItems.length
: Math.ceil(minItemsNeeded / originalItems.length) * originalItems.length;
for (let i = originalItems.length; i < neededItems; i++) {
const clone = originalItems[i % originalItems.length].cloneNode(true);
clone.setAttribute("data-spatial-slider-clone", "");
clone.setAttribute("aria-hidden", "true");
track.appendChild(clone);
}
const items = Array.from(track.querySelectorAll(":scope > [data-spatial-slider-item]"));
const totalItems = items.length;
track.style.height = itemHeight + "px";
container.setAttribute("data-spatial-slider-drag-status", "grab");
items.forEach((item) => item.setAttribute("data-spatial-slider-item-status", "not-active"));
const proxy = document.createElement("div");
proxy.setAttribute("data-spatial-slider-proxy", "");
Object.assign(proxy.style, {
position: "absolute",
width: "1px",
height: "1px",
pointerEvents: "none",
opacity: "0",
});
container.appendChild(proxy);
container._spatialSliderProxy = proxy;
gsap.set(proxy, { x: 0 });
const setX = items.map((item) => gsap.quickSetter(item, "x", "px"));
const setZ = items.map((item) => gsap.quickSetter(item, "z", "px"));
const setRotationY = items.map((item) => gsap.quickSetter(item, "rotationY", "deg"));
const getIndex = () => -gsap.getProperty(proxy, "x") / stepDistance;
const nearestDelta = (index, realIndex) => {
const loop = Math.round((realIndex - index) / totalItems);
return index - (realIndex - loop * totalItems);
};
const getSlideDelta = (target, realIndex) => {
let bestDelta = 0;
let bestDistance = Infinity;
items.forEach((item, index) => {
if (index % originalItems.length !== target) return;
const delta = nearestDelta(index, realIndex);
const distance = Math.abs(delta);
if (distance < bestDistance) {
bestDelta = delta;
bestDistance = distance;
}
});
return bestDelta;
};
let lastActiveIndex = null;
const updateActiveUI = (activeIndex, activeSlideIndex) => {
if (activeIndex === lastActiveIndex) return;
items.forEach((item, index) => {
item.setAttribute(
"data-spatial-slider-item-status",
index === activeIndex ? "active" : "inview"
);
});
indicators.forEach((el) => {
el.textContent = formatNumber(activeSlideIndex + 1);
});
controls.forEach((btn) => {
const value = btn.getAttribute("data-spatial-slider-control");
if (!/^\d+$/.test(value)) return;
const isActive = parseInt(value, 10) - 1 === activeSlideIndex;
btn.setAttribute(
"data-spatial-slider-control-status",
isActive ? "active" : "not-active"
);
btn.setAttribute("aria-current", isActive ? "true" : "false");
});
lastActiveIndex = activeIndex;
};
const render = () => {
const realIndex = getIndex();
const activeIndex = mod(Math.round(realIndex), totalItems);
const activeSlideIndex = activeIndex % originalItems.length;
items.forEach((item, index) => {
const position = getSpatialPosition(nearestDelta(index, realIndex));
setX[index](position.x);
setZ[index](position.z);
setRotationY[index](position.rotationY);
});
updateActiveUI(activeIndex, activeSlideIndex);
};
controls.forEach((btn) => {
const value = btn.getAttribute("data-spatial-slider-control");
btn.disabled = false;
btn.onclick = () => {
gsap.killTweensOf(proxy);
const currentIndex = getIndex();
let targetIndex;
if (value === "next" || value === "prev") {
targetIndex = Math.round(currentIndex) + (value === "next" ? 1 : -1);
} else if (/^\d+$/.test(value)) {
const targetSlide = Math.max(
0,
Math.min(originalItems.length - 1, parseInt(value, 10) - 1)
);
targetIndex = currentIndex + getSlideDelta(targetSlide, currentIndex);
} else {
return;
}
gsap.to(proxy, {
x: -targetIndex * stepDistance,
duration: slideDuration,
ease: clickEase,
onUpdate: render,
});
};
});
container._spatialSliderDraggable = Draggable.create(proxy, {
type: "x",
trigger: collection,
inertia: true,
throwResistance: 2000,
dragResistance: 0.05,
maxDuration: 1,
minDuration: 0.5,
edgeResistance: 0.75,
overshootTolerance: 0,
snap: (value) => Math.round(value / stepDistance) * stepDistance,
onDrag: render,
onThrowUpdate: render,
onThrowComplete: () => {
container.setAttribute("data-spatial-slider-drag-status", "grab");
render();
},
onPress: () => container.setAttribute("data-spatial-slider-drag-status", "grabbing"),
onDragStart: () => container.setAttribute("data-spatial-slider-drag-status", "grabbing"),
onRelease: () => container.setAttribute("data-spatial-slider-drag-status", "grab"),
})[0];
render();
container._spatialSliderImageObserver = new IntersectionObserver(([entry], observer) => {
if (!entry.isIntersecting) return;
container.querySelectorAll('[data-spatial-slider-item] img[loading="lazy"]').forEach((img) => {
img.loading = "eager";
});
observer.disconnect();
});
container._spatialSliderImageObserver.observe(container);
});
if (initSpatialCardsSlider._resize) {
window.removeEventListener("resize", initSpatialCardsSlider._resize);
}
initSpatialCardsSlider._resize = debounceOnWidthChange(initSpatialCardsSlider, 200);
window.addEventListener("resize", initSpatialCardsSlider._resize);
}
function debounceOnWidthChange(fn, ms) {
let lastWidth = window.innerWidth;
let timer;
return function (...args) {
clearTimeout(timer);
timer = setTimeout(() => {
if (window.innerWidth === lastWidth) return;
lastWidth = window.innerWidth;
fn.apply(this, args);
}, ms);
};
}
document.addEventListener("DOMContentLoaded", () => {
initSpatialCardsSlider();
});
if (typeof Lenis === "function") {
const lenis = new Lenis({
autoRaf: true,
});
window.lenis = lenis;
}
````
